| Brand Name: | ICESNOW |
| Model Number: | GM-100KA |
| MOQ: | 1 SET |
| Price: | 1 USD |
| Packaging Details: | WOODEN PACKING |
Main Features
● Daily Capacity: 10ton/day
● Machine power supply: 3P/380V/50HZ,3P/220V/60HZ,3P/380V/60HZ,
● Fully Automatic and safe operation system
● Direct low temperature continuous ice formation, ice temperature below -8 °C, high efficiency
● Cooling type: Water cooling
● Refrigerant gas: R22/R404A/R507
Decription:
1. Use stainless steel 304 / 316 or carbon steel evaporator drum. The scratching-style system inside machine ensures constant running at the lowest power consumption, exquisite welding and processing technology ensure high-efficiency heat transfer and energy saving.
2. Adopt environmentally friendly refrigerant, environmental protection, high efficiency and energy saving
3. Ice blade--Spiral ice blade, small resistance, low loss, no noise and making ice in uniform.
4. The whole machine has passed CE certificate and ISO Certificate, and has high security
Specification:
| Name | Technical Data |
| Ice production | 10ton/24h |
| Refrigeration capacity | 56034Kcal/h |
| Evaporating temp. | -20℃ |
| Condensing Temp. | 40℃ |
| Ambient Temp. | 35℃ |
| Inlet water Temp. | 20℃ |
| Total Power | 38.2kw |
| Compressor Power | 50HP |
| Reducer Power | 0.75KW |
| Water pump Power | 0.37KW |
| Brine Pump | 0.012KW |
| Standard Power | 3P-380V-50Hz |
| Inlet water pressure | 0.1Mpa－0.5Mpa |
| Refrigerant | R404A |
| Flake ice Temp. | -5℃ |
| Feeding water tube size | 1/2" |
| Net weight | 1970kg |
| Dimension of flake ice machine | 3520mm×1920mm×1878mm |
Flake ice Advantages:
1. 2 sets of Bizter Semi-hermitic compressor
Used the international well known brand compressor, which has good lubricating system and the efficiency of the energy adjustment, large cooling capacity and high energy efficiency ratio, wear the driving part, the advantages of compact structure etc.
2. Microcomputer intelligent control: the machine is using PLC control system with world famous brand components, which control the whole ice making process, meanwhile it can protect the machine when there are water shortage, ice full, high/ low-pressure alarm, and motor reversal in order to guarantee the machine run stable with fewer faults.
3. Refrigeration unit: main components all from the leading refrigeration technology countries: the United States, Germany, Japan, etc.
International Brand famous components:
| Item | Name of Components | Brand Name | Original Country |
| 1 | Compressor | Screw Hanbell | Taiwan |
| 2 | Flake ice evaporator/drum | ICESNOW |
China |
| 3 | Water cooled condenser | ICESNOW | |
| 4 | Refrigeration components | DANFOSS/CASTAL | Demark/Italy |
| 5 | PLC Program control | LG (LS) | South Korea |
| 6 | Electrical components | LG (LS) | South Korea |
FAQ:
Q1: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Q2. How to install the machine ?
A: Manual book and video will be provided to guide you how to install the machine, and also our service online.
|
|
