|Ice Shape:||Flake Ice||Voltage:||380v/50hz/3p|
3P Freshwater Flake Ice Machine,
Commercial Freshwater Flake Ice Machine,
3P commercial crushed ice machine
Fresh Water Flake Ice Machine dea
TECHNICAL DATA OF FLAKE ICE MACHINE specification:
|Name||Technical Data||Name||Technical Data|
|Ice production||1000kg/24h||Water pump Power||0.014KW|
|Refrigeration capacity||5603 Kcal||Brine Pump||0.012KW|
|Evaporating temp.||-20℃||Standard Power||3P-380V-50Hz|
|Condensing Temp.||40℃||Inlet water pressure||0.1Mpa－0.5Mpa|
|Inlet water Temp.||20℃||Flake ice Temp.||-5℃|
|Total Power||4.0kw||Feeding water tube size||1/2"|
|Compressor Power||5HP||Net weight||190kg|
|Reducer Power||0.18KW||Dimension (ice machine)||1240mm×800mm×900mm|
* Flake Ice: Dry, pure, powder-less, not easy to block, its thickness is about 1.8mm~2.2mm, without edges or corners which will can product the cooling food, fish, seafood and other products.
*Microcomputer Intelligent Control: the machine is using PLC Control System with world famous brand components. Meanwhile it can protect the machine when there are water shortage, ice full, high/low pressure alarm, and motor reversal.
* Evaporator Drum: Use Stainless Steel material or Carbon Steel chrome-plating. The scratch-style of inside machine ensures constant running at the lowest power consumption.
* The Flake Ice Machine have been applied in refreshing vegetable, fruit, foodstuff in supermarket.
A. Installation for ice machine:
1). Installing by the user: we will test and install the machine before shipment, all necessary spare parts, operation manual and CD are provided to guide the installation.
2). Installing by Icesnow engineers:
(1) We can send our engineer to assist the installation and provide technical support and train your workers. The end-user should provide accommodation and round-trip ticket for our engineer.
(2) Before our engineers’ arrival, the installation place, electricity, water and installation tools should be prepared. Meanwhile, we will provide you a Tool List with the machine when delivery.
(3) 1~ 2 workers are required to assist the installation for big project.
1) 24 months warranty after delivery.
2) Professional after-sales department to provide 24/7 technical support, all complaints should be replied within 24 hours.
3) Over 20 engineers available to service machinery overseas.
4) Free spare parts replacement within warranty period
Contact Person: Andy Hou
