|Ice Shape:||Flake Ice||Voltage:||380v/50hz/3p|
|Temperature Of Flake Ice:||-5℃～-8℃||Ice Thickness:||1.5mm-2.2mm|
Carbon Steel Freshwater Flake Ice Machine,
GM-15KA Freshwater Flake Ice Machine,
1500kg flake ice machine maker
1. Flake Ice: Dry, pure, powder-less, not easy to block, its thickness is about 1.8mm~2.2mm, without edges or corners which will can product the cooling food, fish, seafood and other products.
2. Machine power supply: 3P/380V/50HZ,3P/380V/60HZ,3P/440V/60HZ
3. The equipment can be used with stainless steel ice storage bins or polyurethane ice storage bins, and a wide range of accessories are available.
4. Evaporator Drum: Use Stainless Steel material or Carbon Steel chrome-plating. The scratch-style of inside machine ensures constant running at the lowest power consumption.
1 .Icesnow Series Flake Ice Machine produces flake ice , which can be widely used in many industries. We have two types: fresh water type and seawater type. The daily capacity ranges from 300kg to 100tons in 24 hours(Or we can custom made as per your requests).
2.Thermal insulation: foaming machine filling with imported polyurethane foam insulation. Better effect.
3. High quality , dry and no-caked. The thickness of flake ice which produced by automatic ice flake making machine with vertical evaporator is about 1 mm to 2 mm. The ice shape is irregular flake ice and it has good mobility.
4. Ice blade: made of SUS304 material seamless steel tube and formed through only one time process. It's durable.
|Refrigeration capacity||8405 Kcal|
|Inlet water Temp.||20℃|
|Reducer motor Power||0.18KW|
|Water pump Power||0.014KW|
|Brine water Pump||0.012KW|
|Inlet water pressure||0.1Mpa－0.5Mpa|
|Flake ice Temp.||-5℃|
|Feeding water tube size||1/2"|
|Dimension of flake ice machine||1600mm×940mm×1000mm|
1. Fully automatic control: For possible failure of the flake ice machine, such as voltage phase loss, overload, water shortage, full ice, low voltage and high voltage, it will automatically stop and alarm to ensure the stable operation.
2. Microcomputer Intelligent Control: the machine is using PLC Control System with world famous brand components. Meanwhile it can protect the machine when there are water shortage, ice full, high/low pressure alarm, and motor reversal.
3. Pass the international CE, SGS, ISO9001 and other certification standards, the quality is reliable.
4. Higher refrigeration efficiency and lower loss of refrigeration capacity.
5. 18 months warranty. Life time technical support.
International Brand famous components:
|Item||Name of Components||Brand Name||Original Country|
|2||Ice Maker Evaporator||ICESNOW||
|3||Air cooled condenser||ICESNOW|
|5||PLC Program control||LG (LS)||South Korea|
|6||Electrical components||LG (LS)||South Korea|
