Automatic 40ton Seawater Industrial Flake Ice Machine For Food Preservation

Automatic 40ton Seawater Industrial Flake Ice Machine For Food Preservation
Automatic 40ton Seawater Industrial Flake Ice Machine For Food Preservation Automatic 40ton Seawater Industrial Flake Ice Machine For Food Preservation Automatic 40ton Seawater Industrial Flake Ice Machine For Food Preservation Automatic 40ton Seawater Industrial Flake Ice Machine For Food Preservation

Large Image :  Automatic 40ton Seawater Industrial Flake Ice Machine For Food Preservation

Product Details:
Place of Origin: China
Brand Name: ICESNOW
Certification: CE CERTIFICATE
Model Number: GM-400KA
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: 1 USD
Packaging Details: WOODEN PACKING
Delivery Time: 25 working days

Automatic 40ton Seawater Industrial Flake Ice Machine For Food Preservation

Description
Ice Shape: Flake Ice Voltage: 380v/50hz/3p
Condition: New Material: Carbon Steel
Temperature Of Flake Ice: -5℃~-8℃ Ice Thickness: 1.5mm-2.2mm
Water-feeding Pressure: 0.1Mpa-0.6Mpa
High Light:

40ton industrial flake ice machine

,

Automatic industrial flake ice machine

,

40ton seawater flake ice machine

Automatic 40ton/Day Ice Making Machinery /Ice Maker Flake Used For Food Preservation



Main Features:



● Daily capacity: 40ton/day

● Machine power supply: 3P/380V/50HZ,3P/220V/60HZ,3P/380V/60HZ,

● PLC intelligent control system, fully automated production, no manual operation required

● Icesnow flake ice machine designed based on the features and special requirements of supermarket freshing, lab and health care industry,       applicated to the field which demands high grade of ice flake

● cooling type: water cooled



Decription:



1 .Ice skates: Spiral hob with small resistance and low consumption, ice making evenly without noise


2. Thermal insulation: foaming machine filling with imported polyurethane foam insulation. Better effect.


3. Automatic control: The whole system is automatically controlled and easy to use ;Operation starts by merely switching on one button ,and terminates automatically when ice is full;



4. The ice machine parts are selected from Danish Danfoss, Copeland of America, Bitzer of Germany, Hanbell of Taiwan, Danfoss, and PLC controllers of international famous brands such as Korea PLC controller, with stable performance.





Specification:



Name Technical Data
Ice production 40ton/24h
Refrigeration capacity 22413 Kcal/h
Evaporating temp. -20℃
Condensing Temp. 40℃
Ambient Temp. 35℃
Inlet water Temp. 20℃
Total Power 124.3KW
Reducer Power 2.2KW
Water pump Power 1.5KW
Brine Pump 0.012KW
Standard Power 3P-380V-50Hz
Inlet water pressure 0.1Mpa-0.5Mpa
Refrigerant R404A
Flake ice Temp. -5℃
Feeding water tube size 1/2"
Net weight 5500kg
Dimension (ice machine) 5250mm×2800mm×2876mm





Product Advantage:

1) Adopt environmentally friendly refrigerant, environmental protection, high efficiency and energy saving



2) Safe and reliable: all parts are provided by international cooperating suppliers and every part is strictly tested before using ;A low-hitch protection system is also installed to protect the machine ;By using the highest imported quality components and non-corrosive materials, the flake ice sealed in the freshness safely to prolong the quality of the produce.



3) perfect flexibility :it can be used in an ambient temperature ranging from 5 to 45C°.Specially designed types are able to function normally under the worst conditions.


4) High efficiency of ice making





Suitable Industry:

1. The raw materials storing and precooling of the food processing plant;

2. The lives stock precooling, fresh keeping, freezing and transporting after killing in the meat processing plant;

3. The reaction kettle of chemical plant, raw material cooling and the box-type and environment cooling;

4. Concrete cooling during mixing, concrete adding in the construction industry;

5. Ice factory;

6. The deep-sea fishing and seafood fresh keeping;

7. The mine cooling.

FAQ:



1. Where is your company?

Shenzhen city, Guangdong province, China.



2. Are you a manufacturer?

Yes, we have been offering specialized products in this field for 20 years.



3. When can I get the price?

Usually within 24 hours after we get your inquiry. And if you are very urgent, you can call us or tell us by e-mail so we will prioritize your inquiry.


4. who are we?
We are based in Shenzhne, China, start from 2003,sell to Southeast Asia(30.00%),Africa(21.00%),North America(17.00%),Mid East(8.00%),South America(7.00%),South Asia(5.00%),Domestic Market(5.00%),Eastern Europe(00.00%),Oceania(00.00%),Eastern Asia(00.00%),Western Europe(00.00%),Central America(00.00%),Northern Europe(00.00%),Southern Europe(00.00%). There are total about 101-200 people in our office.



5. what can you buy from us?
Flake Ice Machine,flake ice evaporator,Tube Ice Machine,Block Ice Machine,,Cube Ice Machine,
