Place of Origin:
China
Brand Name:
ICESNOW
Certification:
CE CERTIFICATE
Model Number:
GM-500KA
Main Features
● Machine power supply: 3P/380V/50HZ,3P/220V/60HZ,3P/380V/60HZ,
● PLC intelligent control system, fully automated production, no manual operation required
● Cable Channel: All the wires packed in stainless steel channel, protects the wire, also makes the machine look neat and tidy
● Refrigerating unit -- Main parts of refrigerating units are all from America, Germany, Japan and other countries that have leading refrigeration technology.
Decription:
1 .Ice skates: Spiral hob with small resistance and low consumption, ice making evenly without noise
2. Large contact area:
As its flat and thin shape, it has got the largest contact area among all types of ice. The larger its contact
3. Flake Ice: Flake ice is dry, pure, powder-less, not easy to melt and its temperature can reach -5 degrees. Its thickness is about 1.5mm-2.2mm, without edges or corners which can produce the cooling food, fish, seafood ad other products
4. The ice machine parts are selected from Danish Danfoss, Copeland of America, Bitzer of Germany, Hanbell of Taiwan, Danfoss, and PLC controllers of international famous brands such as Korea PLC controller, with stable performance.
Specification:
| Name | Technical Data |
| Ice production | 50ton/24h |
| Refrigeration capacity | 280172 Kcal/h |
| Evaporating temp. | -20℃ |
| Condensing Temp. | 40℃ |
| Ambient Temp. | 35℃ |
| Inlet water Temp. | 20℃ |
| Total Power | 147.4KW |
| Reducer Power | 2.2KW |
| Water pump Power | 1.5KW |
| Brine Pump | 0.012KW |
| Standard Power | 3P-380V-50Hz |
| Inlet water pressure | 0.1Mpa－0.5Mpa |
| Refrigerant | R404A |
| Flake ice Temp. | -5℃ |
| Feeding water tube size | 1/2" |
| Net weight | 6300kg |
| Dimension (ice machine) | 5250mm×2800mm×2876mm |
Product Advantage:
1. Profession in making flake ice machine;
2. Having own research and development team, achieves the product promptly renewal;
3. Advanced processing facility;
4. High QA control, deliver on time
5. OEM/ ODM is available, till customers are satisfied;
Flake Ice Machine Application:
• Mincer process for boiled sausage production
• Production of baking and pastry products
• Fishing industry: cooling during transportation, storage and sale.
• Artificial snow tracks for sports and leasure
• Concrete cooling for large project, like railway hydropower project
FAQ:
1. How about the after-sales services?
Icesnow provide 2 years warranty for our machine. For after sales service, once out of work, you only need to send us pictures or video about the fault, we will mail you the solution to solve problems within 24 hours.
2. What about the standard conditions?
The technical data based on 30°C ambient temp 25°C water inlet temp.
If your local condition is different from it, you can consult us first, then choose the proper ambient temperature.
3. What should i do before i get the price?
Please provide some information with our salesman, such as how many tons of ice do you want to produce/consume per day? what is the voltage, phase and frequency in your side and do you have any requirements about the size of the ice? after we konw these, According to all your requirements ,we can make a quotation sheet to you that is completely belong to you.
4. How can i konw your factory is ture?
If it is convenient for you, we warmly welcome you to visit our factory in china, but if it is not convenient for you to come to our factory, Don't worry! please tell our salesmen your whatsapp number, she will show your our factory and machines by video, and show you everything what can prove we are a real factory.
