PLC 15 Ton Direct Cooling Block Ice Machine Ice Block Making Plant

PLC 15 Ton Direct Cooling Block Ice Machine Ice Block Making Plant
PLC 15 Ton Direct Cooling Block Ice Machine Ice Block Making Plant PLC 15 Ton Direct Cooling Block Ice Machine Ice Block Making Plant PLC 15 Ton Direct Cooling Block Ice Machine Ice Block Making Plant PLC 15 Ton Direct Cooling Block Ice Machine Ice Block Making Plant

Large Image :  PLC 15 Ton Direct Cooling Block Ice Machine Ice Block Making Plant

Product Details:
Place of Origin: China
Brand Name: ICESNOW
Certification: CE CERTIFICATE
Model Number: ISN-ZK150
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: 1 USD
Packaging Details: WOODEN PACKING
Delivery Time: 30 working days

PLC 15 Ton Direct Cooling Block Ice Machine Ice Block Making Plant

Description
Ice Shape: Block Ice Voltage: 380v/50hz/3p
Condition: New Material: Aluminium Plate
Compressor Brand: Hanbell Weight: 25kg/50kg
High Light:

15 Ton Direct Cooling Block Ice Machine

,

PLC Direct Cooling Block Ice Machine

,

15Ton ice block making plant

High Efficiency 15 Ton Direct Cooling Block Ice Machine Ice Block Maker Machine with Aluminum Plate for Food Factory





Main Features:



1. Power consumption: about 75-85KW*H to make 1 ton ice, it depends on the ambient temperature.



2. Adopt PLC program centralized control, auto water supplying and auto ice dropping.



3. It's our new design of ice block machine, break through the traditional design. No need to add chemical to the machine.



4. We adopt Bitzer Compressor (Germany brand);
Danfoss/Castal refrigeration components (Denmark/Italy brand);
LG/LS electrical parts (South Korea brand)
This excellent combination and the first-class refrigerant components of the world with the characteristics of high efficiency, energy saving and low noise.





Product Description:



1.The ice blocks are clean and hygienic: the water quality is up to standard and the ice blocks can be eaten.



2. Block ice can be changeable: 5-100kg per piece, you can choose what you like, we can also design according to customers' special requirements.



3. Anti-rust and Anti-corrosion material: We use Aluminum plate to make ice cans, it is a good material anti-rust and anti-corrosive, the ice is clean and beautiful, meanwhile the lifespan can be longer.



4. Edible ice block machine the biggest features is that the large-scale ice blocks no need salty water and other cooling medium during the freezing period.



PLC 15 Ton Direct Cooling Block Ice Machine Ice Block Making Plant 0

Specification:



Model ISN-ZK150
Cooling Capacity (kw) 135KW
Daily capacity 15Ton/day
Rated Power (kw) 60kw
Compressor brand Screw Hanbell
Compressor power 47KW
Refrigerant gas R404A/R22/R507
Power supply 3P/380V/50Hz
Each Ice Block weight(kg) 25kg/50kg
Dimension of block ice evaporator 5650*2110*2280mm
Dimension of condensing unit 3120*2300*2100mm





Advantages of our block ice machine:



1). Special design evaporator aluminum plates conform to food standards.



2). Top quality and Best price you can never imagine.



3). Module design, the whole set consists of machine unit module, evaporator module, and cooling tower module; easy to ship and install.



4). Easy operation and convenient transportation, low cost.



5). Module design, the whole set consists of machine unit module, evaporator module, and cooling tower module; easy to ship and install.



Ice size for choice, or the ice size can be customized according to your need.



Ice Size/pc Ice Dimension (mm)
(Thickness*Width*Height)
Freezing Time
(Hours)
Ice Making
Frequency (Times)
5KG 95*130*500 3 7
10KG 95*260*500 3 7
15KG 123*300*500 8 3
123*215*710 8 3
20KG 123*285*710 8 3
25KG 123*350*710 8 3
155*280*710 8 3
30KG 155*315*710 8 3
50KG 410*160*925 12 2



PLC 15 Ton Direct Cooling Block Ice Machine Ice Block Making Plant 1

FAQ:



Q1: Are you factory or trade company?
A: We are factory,have our own machines,workers,R&D department.Sales and after-sale department.


Q2. What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance. You're welcome to see the test of the machines for days.


Q3. How about your delivery time?
A: Generally, it will take 25 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.



Q4.What can you do for us?

A:All material/color/size are available, also we can customize products as your requirements. Any questions, pls don't hesitate to contact us!
