Supermarket Freshwater Flake Ice Maker Machine Commercial 1000kg/Day

Supermarket Freshwater Flake Ice Maker Machine Commercial 1000kg/Day
Supermarket Freshwater Flake Ice Maker Machine Commercial 1000kg/Day Supermarket Freshwater Flake Ice Maker Machine Commercial 1000kg/Day

Large Image :  Supermarket Freshwater Flake Ice Maker Machine Commercial 1000kg/Day

Product Details:
Place of Origin: China
Brand Name: ICESNOW
Certification: CE CERTIFICATE
Model Number: GM-10KA
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 1 USD
Packaging Details: WOODEN PACKING

Supermarket Freshwater Flake Ice Maker Machine Commercial 1000kg/Day

Description
Ice Shape: Flake Ice Voltage: 380v/50hz/3p
Condition: New Material: Stainless Steel
Cooling Mode: Air Cooling
High Light:

Supermarket flake ice maker

,

Commercial flake ice maker

,

Freshwater flake ice machine commercial

1000kg/Day Stainless Steel Freshwater Flake Ice Machine with Stainless Steel Ice Bin For Supermarket



Fresh Water Flake Ice Machine Features:

1 .Higher refrigeration efficiency and lower loss of refrigeration capacity.
2. Automatic salt water flake ice machine adpots the latest vertical evaporator with inner helix ice cutter. In the process of ice making, the water distribution device in ice maker sprays water even on the internal surface of ice maker to frozen in a short time . After ice formed , the helix ice cutter drops down and cut ice . In this method, it makes a full use of evaporator and increase the efficiency of ice making.

3. All Material: stainless Steel

Decription:

1. High quality , dry and no-caked. The thickness of flake ice which produced by automatic ice flake making machine with vertical evaporator is about 1 mm to 2 mm. The ice shape is irregular flake ice and it has good mobility.


2. Simple structure and small land area .

3. Ice blade: made of SUS304 material seamless steel tube and formed through only one time process. It's durable.





TECHNICAL DATA OF FLAKE ICE MACHINE specification:

Name Technical Data Name Technical Data
Ice production 1000kg/24h Water pump Power 0.014KW
Refrigeration capacity7KW   Brine Pump 0.012KW
Evaporating temp. -25℃ Standard Power 3P-380V-50Hz
Condensing Temp. 40℃ Inlet water pressure 0.1Mpa-0.5Mpa
Ambient Temp. 35℃ Refrigerant R404A
Inlet water Temp. 20℃ Flake ice Temp. -5℃
Total Power 4.0kw Feeding water tube size 1/2"
Compressor Power 5HP Net weight 190kg
Reducer Power 0.18KW Dimension (ice machine) 1240mm×800mm×900mm





Product Advantages:

Flake Ice: Dry, pure, powder-less, not easy to block, its thickness is about 1.8mm~2.2mm, without edges or corners which will can product the cooling food, fish, seafood and other products.

Microcomputer Intelligent Control: the machine is using PLC Control System with world famous brand components. Meanwhile it can protect the machine when there are water shortage, ice full, high/low pressure alarm, and motor reversal.

Evaporator Drum: Use Stainless Steel material or Carbon Steel chrome-plating. The scratch-style of inside machine ensures constant running at the lowest power consumption.

The Flake Ice Machine have been applied in refreshing vegetable, fruit, foodstuff in supermarket.





FAQ

A. Installation for ice machine:

1). Installing by the user: we will test and install the machine before shipment, all necessary spare parts, operation manual and CD are provided to guide the installation.



2). Installing by Icesnow engineers:



(1) We can send our engineer to assist the installation and provide technical support and train your workers. The end-user should provide accommodation and round-trip ticket for our engineer.



(2) Before our engineers’ arrival, the installation place, electricity, water and installation tools should be prepared. Meanwhile, we will provide you a Tool List with the machine when delivery.





(3) 1~ 2 workers are required to assist the installation for big project.







B. Warranty:

1) 24 months warranty after delivery.



2) Professional after-sales department to provide 24/7 technical support, all complaints should be replied within 24 hours.



3) Over 20 engineers available to service machinery overseas.



4) Free spare parts replacement within warranty period
