Place of Origin:
China
Brand Name:
ICESNOW
Certification:
CE CERTIFICATE
Model Number:
ISN-ZK20
Environmental Friendly 2Ton/day Brine Type Block Ice Machine Ice Block Making Plant for Fishery
Main Features:
1. The traditional craft of brine heat ice, ice machine running stable, low failure rate;
2. The block ice machine is energy saving. Ice making power consumption had declined greatly.
3. The ice mold can be made of galvanized sheet or stainless steel;
4. The machine process of ice is the full automatic control; don't need a professional people with certificates;
5. Daily production: 2 tons per day.
Product Description:
1.Block ice size: 5kg, 10kg, 15kg, 20kg, 25kg, 30kg, 50kg, 100kg, etc. And we can also design the ice block size according to customers' needs.
2. Agitator makes the brine flowing faster, so that shorten the ice frozen time. And agitator is much harder to be broken than water pump.
3. Ice making tank adopts 80mm thickness polyurethane insulation material. It has good effect in heat insulation.
4. Supply power: 380V-3P-50Hz or 220V-3P-60Hz
Specification:
| Model | ISN-ZK20 | |
| Cooling Capacity (kw) | 135KW | |
| Daily capacity | 2Ton/day | |
| Rated Power (kw) | 60kw | |
| Compressor brand | Screw Hanbell | |
| Compressor power | 47KW | |
| Refrigerant gas | R404A/R22/R507 | |
| Power supply | 3P/380V/50Hz | |
| Each Ice Block weight(kg) | 50kg | |
| Dimension of block ice evaporator | 5650*2110*2280mm | |
| Dimension of condensing unit | 3120*2300*2100mm | |
Advantages of our block ice machine:
1). The ice moulds and salt water tank are made of stainless steel 304 material, which is anti-rust and anti-corrosive and life span is longer.
2). Modular structure and integrated design, save space, flexible move, easy to install and harvest ice on the spot.
3). Low energy consumption, low maintenance, safe and reliable, environmentally friendly and high capacity.
4). Easy operation and convenient transportation, low cost.
5).All dimensions of ice block machines are designed according to the international standard size of the container to ensure they are easy to ship and convenient for transportation.
| Ice Size/pc | Ice Dimension (mm) (Thickness*Width*Height) |
Freezing Time (Hours) |
Ice Making Frequency (Times) |
| 5KG | 95*130*500 | 3 | 7 |
| 10KG | 95*260*500 | 3 | 7 |
| 15KG | 123*300*500 | 8 | 3 |
| 123*215*710 | 8 | 3 | |
| 20KG | 123*285*710 | 8 | 3 |
| 25KG | 123*350*710 | 8 | 3 |
| 155*280*710 | 8 | 3 | |
| 30KG | 155*315*710 | 8 | 3 |
| 50KG | 410*160*925 | 12 | 2 |
Application:
FAQ:
Q1: Are you factory or trade company?
A: We are factory,have our own machines,workers,R&D department.Sales and after-sale department.
Q2. What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance. You're welcome to see the test of the machines for days.
Q3. How many ice block can make it?
A: It is custome made products, you can get 100pcs, 200pcs, 500pcs, 1,000pcs or more ice block, each ice block can make 5kg, 10kg, 20kg 50kg.. such as if you want 500 pcs 10kg ice block, then it is 5,000kg capacity per day, we can supply and quote according to this.
Q4.What can you do for us?
A:All material/color/size are available, also we can customize products as your requirements. Any questions, pls don't hesitate to contact us!
Q5: The ice block machine for sale tests the pH once a month?
A: PH value between 7-8
