Automatic Containerized Block Ice Machine 5Ton

Automatic Containerized Block Ice Machine 5Ton
Automatic Containerized Block Ice Machine 5Ton Automatic Containerized Block Ice Machine 5Ton Automatic Containerized Block Ice Machine 5Ton Automatic Containerized Block Ice Machine 5Ton

Large Image :  Automatic Containerized Block Ice Machine 5Ton

Product Details:
Place of Origin: China
Brand Name: ICESNOW
Certification: CE CERTIFICATE
Model Number: ISN-ZK50
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: 1 USD
Packaging Details: WOODEN PACKING
Delivery Time: 30 working days

Automatic Containerized Block Ice Machine 5Ton

Description
Ice Shape: Block Ice Voltage: 380v/50hz/3p
Condition: New Material: Galvanized Steel
Compressor Brand: Bizter Weight: 50kg/25kg/10kg
Cooling Mode: Water Cooling
High Light:

Automatic Containerized Block Ice Machine

,

5Ton Containerized Block Ice Machine

,

5Ton Containerized Ice Machine



Automatic Control 5Ton/day Block Ice Machine Ice Block Making Plant Weight 50kg Ice Mold





Main Features:



1. The traditional craft of brine heat ice, ice machine running stable, low failure rate;


2. According to customer requirements, design suitable block ice machine for the customer request;


3. The ice mold can be made of galvanized sheet or stainless steel;


4. The machine process of ice is the full automatic control; don't need a professional people with certificates;


5. Supply power: 380V-3P-50Hz or 220V-3P-60Hz



6. Freezing time: 10~12hours





Product Description:



1.Block ice size: 5kg, 10kg, 15kg, 20kg, 25kg, 30kg, 50kg, 100kg, etc. And we can also design the ice block size according to customers' needs.



2. Thawing tank:Heated by hot gas discharged from the compressor so that it is more energy saving and suitable for low water temperature area.



3. The ice block machine adopts separate design for the ice block machinery unit and water tank part, which is easy to install and maintenance. Meanwhile you just need to connect water pipes and power lines to the machine.



4. The capacity can be designed based on your demands, it is very flexible.





Specification:



Model ISN-ZK50
Cooling Capacity (kw) 135KW
Daily capacity 5Ton/day
Rated Power (kw) 60kw
Compressor brand Screw Hanbell
Compressor power 47KW
Refrigerant gas R404A/R22/R507
Power supply 3P/380V/50Hz
Each Ice Block weight(kg) 50kg
Dimension of block ice evaporator 5650*2110*2280mm
Dimension of condensing unit 3120*2300*2100mm





Advantages of our block ice machine:



1). The ice moulds and salt water tank are made of stainless steel 304 material, which is anti-rust and anti-corrosive and life span is longer.



2). Modular structure and integrated design, save space, flexible move, easy to install and harvest ice on the spot.



3). Compact machine structure makes machine humanized to operate and maintain.



4). PLC(Programmable Logic Controller) system controls the ice making process automatically which makes the machine labor-saving.



5).High density and good apparent:The brine block is not easy to break during movement for it has more density than direct block ice, and brine block is more durable to heat, wind and sunshine, which mean more storage period, What's more, brine block have good looks, it has classic color attractive to eyes.



Ice Size/pc Ice Dimension (mm)
(Thickness*Width*Height)
Freezing Time
(Hours)
Ice Making
Frequency (Times)
5KG 95*130*500 3 7
10KG 95*260*500 3 7
15KG 123*300*500 8 3
123*215*710 8 3
20KG 123*285*710 8 3
25KG 123*350*710 8 3
155*280*710 8 3
30KG 155*315*710 8 3
50KG 410*160*925 12 2











Applications:

1. Ice factory of the ports and docks,

2. Fressh for aquatic products,

3. Cooling,

4. Distance transportation

5. Fishery

6. Food preservation

7. Special areas of cooling

8. Ice sculpture.



Business partner:

Automatic Containerized Block Ice Machine 5Ton 0







FAQ:



Q1: Are you factory or trade company?
A: We are factory,have our own machines,workers,R&D department.Sales and after-sale department.


Q2. What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance. You're welcome to see the test of the machines for days.


Q3. Do we need other equipment to start ice block business?

A: Considering to ice block business running in long term, you can get ice storage room to store ice block and whenever client buy ice, you have enough ice to sell from ice storage room



Q4: What is the life using of this ice block machine ?

A: It adopts famous refirgeration components and machine can use more than 15 years and it is easy to replace the spare parts and we have detailed manuel book to guide





Q5:Do we need other equipment to start ice block business?

A: Considering to ice block business running in long term, you can get ice storage room to store ice block and whenever client buy ice, you have enough ice to sell from ice storage room



Q6: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;

2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.



Q7. What is your aim?
A: And we would be happy that our customers using our brand Icesnow across our world. We aim to give cutomer best products with reasonable price.
