1Ton Small Water Cooled SS304 Commercial Freshwater Flake Ice Machine For Supermarket

1Ton Small Water Cooled SS304 Commercial Freshwater Flake Ice Machine For Supermarket
1Ton Small Water Cooled SS304 Commercial Freshwater Flake Ice Machine For Supermarket 1Ton Small Water Cooled SS304 Commercial Freshwater Flake Ice Machine For Supermarket

Large Image :  1Ton Small Water Cooled SS304 Commercial Freshwater Flake Ice Machine For Supermarket

Product Details:
Place of Origin: China
Brand Name: ICESNOW
Certification: CE CERTIFICATE
Model Number: GM-10KA
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 1 USD
Packaging Details: WOODEN PACKING
Delivery Time: have stock

1Ton Small Water Cooled SS304 Commercial Freshwater Flake Ice Machine For Supermarket

Description
Ice Shape: Flake Ice Voltage: 380v/50hz/3p
Condition: New Material: Carbon Steel
High Light:

1Ton Freshwater Flake Ice Machine

,

SS304 Freshwater Flake Ice Machine

,

SS304 water cooled commercial ice machine

Small Capacity 1Ton/Day Freshwater Flake Ice Machine With SS304 Stainless Steel Ice Bin For Supermarket



Fresh Water Flake Ice Machine Features:

1 .Higher refrigeration efficiency and lower loss of refrigeration capacity.
2. Automatic salt water flake ice machine adpots the latest vertical evaporator with inner helix ice cutter. In the process of ice making, the water distribution device in ice maker sprays water even on the internal surface of ice maker to frozen in a short time . After ice formed , the helix ice cutter drops down and cut ice . In this method, it makes a full use of evaporator and increase the efficiency of ice making.
3. High quality , dry and no-caked. The thickness of flake ice which produced by automatic ice flake making machine with vertical evaporator is about 1 mm to 2 mm. The ice shape is irregular flake ice and it has good mobility.
4. Simple structure and small land area .

Decription:

1. High quality , dry and no-caked. The thickness of flake ice which produced by automatic ice flake making machine with vertical evaporator is about 1 mm to 2 mm. The ice shape is irregular flake ice and it has good mobility.


2. Simple structure and small land area .

3. Ice blade: made of SUS304 material seamless steel tube and formed through only one time process. It's durable.



TECHNICAL DATA OF FLAKE ICE MACHINE specification:

Name Technical Data Name Technical Data
Ice production 1000kg/24h Water pump Power 0.014KW
Refrigeration capacity 5603 Kcal Brine Pump 0.012KW
Evaporating temp. -20℃ Standard Power 3P-380V-50Hz
Condensing Temp. 40℃ Inlet water pressure 0.1Mpa-0.5Mpa
Ambient Temp. 35℃ Refrigerant R404A
Inlet water Temp. 20℃ Flake ice Temp. -5℃
Total Power 4.0kw Feeding water tube size 1/2"
Compressor Power 5HP Net weight 190kg
Reducer Power 0.18KW Dimension (ice machine) 1240mm×800mm×900mm





Product Advantages:

Flake Ice: Dry, pure, powder-less, not easy to block, its thickness is about 1.8mm~2.2mm, without edges or corners which will can product the cooling food, fish, seafood and other products.

*Microcomputer Intelligent Control: the machine is using PLC Control System with world famous brand components. Meanwhile it can protect the machine when there are water shortage, ice full, high/low pressure alarm, and motor reversal.

Evaporator Drum: Use Stainless Steel material or Carbon Steel chrome-plating. The scratch-style of inside machine ensures constant running at the lowest power consumption.

The Flake Ice Machine have been applied in refreshing vegetable, fruit, foodstuff in supermarket.





FAQ:

1. Questions before quotation

A. Would you make ice from freshwater, saltwater or seawater?

B. Where and when would the machine be installed roughly?The ambient temperature and water inlet temperature?

C. What’s the power supply?

D. What is the application of the flake ice machine?

E. Which cooling mode would you prefer to? Water cooling or air cooling ,Evaporative cooling?



2. Warranty & Technical support

A. 2 years after Bill of Lading date.

B. Any failure occurred within the period due to our responsibility, ICESNOW will supply the spare parts for free.

C. ICESNOW provide full technical support and training courses after equipment installation and commissioning.

C. Permanent technical support & consultation all life long for the machines.

D. Over 30 engineers for instant after-sale services and more than 20 are available for serving overseas.

365 days X 7 X 24 hours phone / EMAIL assistance





3. What are your advantages?

We ensures our products can reach the strict quality standards and the goods can be delivered on time.

We provide warmly and friendly service and after-sale service.

We will reply you within 24 hours.

We guarantee the best price and multiple choices.
